Description
The Dahua DHI-VTO2202F-P-S2 is a 2-wire IP Villa Door Station designed for secure and convenient residential access. Featuring a 2MP HD fisheye camera with low-light CMOS sensor, it provides clear video intercom functionality and access control supporting up to two locks. Compatible with 2-wire and RJ45 interfaces, and supporting H.265 video compression, this door station offers reliable PoE installation and flexible surface or flush mounting. Its anodized aluminum front panel, IK07 vandal resistance, and IP65 weatherproof rating make it durable for outdoor use.
Features:
- Anodized alumimum front panel.
- CMOS low illumination 2MP HD colorful 160° fisheye camera.
- Video intercom function.
- Access control function that supports two locks.
- Mobile phone app, talk to the visitor or unlock the door remotely on your phone.
- Compatible with 2-wire interface & RJ45 interface.
- IK07&IP65.
- Support H.265.
- Support surface and flush mount.
- PoE.
Specifications
System | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor | Embedded processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded Linux Operation System | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Button Type | Mechanical | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF; CGI | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | SIP; P2P; IPv4; UPnP; SNMP; DNS; DDNS; RTSP; RTP; TCP; UDP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera | 1/2.5" 2MP CMOS Low Illumination HD Colorful Fisheye Camera | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | Horizontal: 168.6°; vertical: 87.1; diagonal:176.7° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 1.9 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.265 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Resolution | 50Hz: Main Stream (720P@25 fps), sub stream (1080P@25 fps) 60Hz: Main Stream (720P@30 fps), sub stream (1080P@30 fps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Frame Rate | 25 fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | 256 Kbps to 4 Mbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Light Compensation | Auto IR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | Auto (ICR) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711u | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | Built-in speaker | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Mode | 2-way voice communication | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Enhancement | Echo suppression/digital noise reduction | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Bit Rate | 16 KHz, 16 Bit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Status Indicator Light | 3 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electric Lock | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Output | 1-ch 12 VDC 100mA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Exit Button | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Status Detection | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lock Control | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Port | One RJ45 10M/100M network port | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Appearance color | Silver | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | Dahua 2-wire switch (max. power supply distance 50 m) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Adapter | Optional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation | Flush/surface mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE; FCC; UL | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory | Flush/surface mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 130 mm × 96 mm × 28.5 mm (5.12" × 3.78" × 1.12") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection | IK07; IP65 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | –30°C to +60°C (–22°F to 140°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 10%–90% (RH, non-condensing) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Altitude | 0 m–3000 m | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | ≤ 12W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 0.35 kg (0.77 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 0.4 kg (0.88 lb) |
