Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna

SKU:
01DV314L
UPC:
9340591004232
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
  • Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna
Log in for pricing

Description

Digitek LTE Series 14 Element Outer Fringe Premium YAGI VHF Antenna

Features:

  • F-Type Balun with LTE Low Pass Filter
  • Snap out reflectors
  • Stainless Steel screws on connection points
  • Heavy Duty construction on all components
  • Designed & engineered in Australia for Australianconditions & Australian digital television transmissions
  • 12mm extruded aluminium heavy-duty elements
  • Tough powder coated finish
  • UV stabilised plastics
  • Bifurcated rivets - Strongest in the industry
  • Horizontal and vertical mounting options
  • U-bolts & Clamps fitted
  • Complete with extra support boom

View AllClose

Specifications

Specifications
  • Antenna Category: VHF
  • Antenna Type: Yagi
  • Antenna Elements: 14
  • Antenna Band: Band 3 (Channels 6 - 12)
  • Antenna Filter: LTE (4G/5G)
  • Antenna Max Gain: VHF >17.5dB
  • Antenna Front to Back Ratio: 30dB
  • Antenna Materials: Aluminium, UV Stabilised Plastics
  • Antenna Dimensions: 3430mm x 1318mm x 600mm (L x W x H)
  • Colour: Charcoal (Hammertone), Silver Elements
  • Packaging: Poly Bag with Label
  • Warranty: 3 Year
    Included Accessories
  • Rubber Boot (For F Connector), V Block & U Bolt fitted to antenna
    Pack Quantities
  • Carton Quantity: 5
  • Pallet Quantity: 60
    • View AllClose

    Details

    Antenna Category:
    VHF
    Antenna Band:
    Band 3 (Channels 6 - 12)
    Antenna Type:
    Yagi
    Antenna Elements:
    14
    Antenna Filter:
    LTE (4G/5G)
    Antenna Max Gain:
    VHF>17.5dB
    Antenna Front to Back Ratio:
    30dB
    Antenna Materials:
    Aluminium, UV Stabilised Plastics
    Colour:
    Charcoal (Hammertone), Silver Elements
    Antenna Dimensions:
    3430mm x 1318mm x 600mm (L x W x H)
    Included Accessories:
    Rubber Boot (For F Connector), V Block & U Bolt fitted to antenna
    Unit Packaging:
    Poly Bag with Label
    Warranty:
    3 Years
    Carton Quantity:
    5
    Pallet Quantity:
    60
    Product Information Sheet:
    VIEW PDF
    View AllClose
