Digitek RG59 BU 95% 100m Reel

Secure flawless video and data transmission with the Digitek 02ADRG59BUR1 RG59BU Coaxial Cable 95% Cu Braid - 100m Reel, a high-performance RG59 solution built for demanding CCTV, analog TV, and satellite installations. Featuring a robust 0.58mm bare copper conductor, solid polyethylene dielectric, and an impressive 95% bare copper braid coverage with 128 strands of 0.12mm wire, this cable delivers superior shielding against interference, ensuring sharp, noise-free signals over long distances. With low attenuation rates—from under 2.95 dB/100m at 5 MHz to 40.60 dB/100m at 1000 MHz—it supports high-frequency applications like HD video feeds and broadband without degradation.

Encased in a durable 0.90mm UV-stabilized PVC jacket (6.15mm overall diameter), it's designed for outdoor resilience and easy routing in conduits or walls, operating reliably from -15°C to 75°C. The 75-ohm impedance, 82% velocity of propagation, and 3000V conductor-to-shield rating make it a go-to for professional security systems, home surveillance, or legacy video setups. Wound on a convenient 100-meter reel for bulk efficiency, it includes a 1-year warranty for trusted performance. Upgrade your connectivity with Digitek's precision-engineered coax—crystal-clear visuals and unbreakable reliability, every time!

Key Features:

• Premium Bare Copper Construction: 0.58mm solid conductor with 95% copper braid (128 x 0.12mm strands) for exceptional EMI/RFI rejection and low-loss signal integrity in CCTV and video applications.
• Optimized Dielectric Design: 3.71mm solid polyethylene with 1.47mm thickness ensures 75±3 ohm impedance and 82% velocity, minimizing distortion for analog and digital signals up to 1000 MHz.
• Low Attenuation Performance: Superior ratings like <12.30 dB/100m at 100 MHz and <40.60 dB/100m at 1000 MHz, ideal for long-run installations without signal drop.
• Rugged UV PVC Jacket: 0.90mm thick, weather-resistant sheath (6.15mm diameter) withstands UV exposure and environmental stresses for indoor/outdoor use.
• High Electrical Standards: 3000V inner voltage rating, >1000 MΩ insulation resistance, and 53 pF/m capacitance for safe, stable operation in security and broadcast systems.
• VSWR Excellence: <1.2 return loss (>20 dB) across full sweep, guaranteeing efficient power transfer and reduced reflections in antenna or camera feeds.
• Convenient 100m Reel: Easy-dispense packaging for precise cuts in large projects, backed by a 1-year warranty for professional-grade durability.
