Kingray KCC110 Digital Channel Converter/Processor

Kingray KCC110 Programmable Channel Converter / Processor - Australian Made VHF/UHF TV Signal Processor

The Kingray KCC110 is a fully programmable, Australian-designed-and-manufactured VHF/UHF channel converter and processor that delivers unmatched performance in commercial MATV systems, apartment blocks, hotels, and large free-to-air TV installations.

Whether you need to convert a channel to a new frequency to avoid interference or simply process an existing channel for cleaner output, the KCC110 excels at adjacent channel operation on both input and output – made possible by double SAW filtering, input AGC circuitry, and adjustable output power. This results in superior selectivity, low phase noise, and high linearity even in crowded RF environments.

Programming is fast and flexible: use the front-panel USB port when standalone, or connect to a Kingray KLA110 launch amplifier for Ethernet/VPN remote control and monitoring. Bandwidth and output level are fully adjustable, with 125 kHz step resolution for precise frequency placement.

Housed in a rugged die-cast chassis, the KCC110 can be used standalone or mounted in a standard 19-inch rack (1RU with optional kit).

Key Features:

• Australian Made – Designed and manufactured in Australia with full local support
• Full Frequency Range – 44–862 MHz (VHF & UHF)
• 80 dBµV Maximum Output Level – Powerful enough for large distribution systems
• Double SAW Filtering – Outstanding adjacent channel rejection
• Input AGC Circuitry – Maintains stable performance across wide input ranges
• Adjustable Output Power & Bandwidth – Fine-tune for any installation
• 125 kHz Step Resolution – Ultra-precise channel placement
• Adjacent Channel Capable In & Out – Ideal for dense urban environments
• Programmable via USB or Ethernet (through KLA110 with remote VPN access)
• -30 dB Test Point – Easy signal monitoring
• Rack Mountable or Standalone – Die-cast housing 248 × 190 × 30 mm (H x D x W)
• F-Type Connectors – Industry standard
• Low Power Consumption – 500 mA @ 24 V DC
• 3-Year Kingray Warranty – Peace of mind for commercial installations

In the box:

• KCC110
• 2 × RF linking cables
• 1 x DC power lead
• Instruction manual

Upgrade your headend with the professional-grade Kingray KCC110 – the Australian-made converter/processor trusted by installers for rock-solid, interference-free digital TV performance.
