Digitek 20BDAM38 3x8 Satellite & Terrestrial Distribution Amplifier

SKU:
20BDAM38
  • Digitek 20BDAM38 3x8 distribution amplifier front view with 8 F-Type output ports, power adapter and DIP switches for signal control
  • Digitek 20BDAM38 3x8 distribution amplifier front view with 8 F-Type output ports and DIP switches for signal control
  • Digitek 20BDAM38 3x8 Satellite & Terrestrial Distribution Amplifier
  • Digitek 8-port satellite terrestrial amplifier power adapter
  • Packaging Box of  Digitek 8-port satellite terrestrial amplifier
Log in for pricing

Description

The Digitek 20BDAM38 3x8 Satellite & Terrestrial Distribution Amplifier is a robust, high-capacity solution for large-scale TV signal distribution in settings like hotels, apartments, or commercial venues. With a frequency range of 47-694 MHz (TER/Return) and 950-2150 MHz (SAT), this 8-output amplifier ensures seamless signal delivery across multiple devices. Featuring F-Type female connectors, it provides 15 dB TER insertion gain (≥13 dB), 0 dB SAT gain (≥-2 dB), and 3 dB return path gain (≥1 dB), with DIP-switch-controlled gain for precise adjustments.

Designed for demanding SMATV and IRS systems, the 20BDAM38 supports LNB powering (500mA max at 18VDC) and a terrestrial return path for bidirectional setups. It boasts exceptional isolation (up to 39 dB at 694/862 MHz) and low return loss (6-10 dB) to prevent signal interference. With a low power draw (250mA max without LNB/TER) and a 1A 18VDC external power supply, it’s built for efficiency and scalability in professional installations.

Features:

  • High-Capacity 8 Outputs: Distributes SAT and TER signals to multiple devices, perfect for large-scale installations.
  • Comprehensive Frequency Range: Supports 47-694 MHz (TER/Return) and 950-2150 MHz (SAT) for full CATV/SAT compatibility.
  • Powerful Amplification: 15 dB TER gain (≥13 dB), 0 dB SAT (≥-2 dB), and 3 dB return path (≥1 dB) for consistent performance.
  • Superior Isolation: 25-39 dB port isolation, including 39 dB at 694/862 MHz, for noise-free signal distribution.
  • LNB & Power Efficiency: 500mA LNB power at 18VDC; 250mA max consumption without loads for cost-effective operation.
  • Customizable & Durable: DIP switches for TER source (SAT+TER/TER) and 14V power; F-Type connectors for reliable setups.
