Digitek Galvanic Power Isolator 3KV 5-2000Mhz

Protect your CATV network from electrical hazards and ensure seamless signal flow with the Digitek Galvanic Power Isolator 3KV Freq 5-2000MHz, a robust inline safeguard that delivers full galvanic isolation up to 3kV DC for one minute while maintaining excellent screening via capacitive and inductive coupling across 5-1000MHz—like a silent electrical moat that blocks surges and ground loops without disrupting your HD video or audio transmission. Ideal for cable operators, installers, or home setups where equipment safety meets signal purity, this F-Type female output connector complies fully with IEC safety (60728-1 §9) and EMC standards (60728-2 §4.4), featuring ultra-low leakage currents (0.7mA inner conductor, 2.0mA RMS outer at 230V 50/60Hz) and 1.5dB/octave attenuation above 40MHz for superior noise reduction. With a high return loss and impedance match, it's the go-to for preventing damage from transients, ringers, or power supplies in antenna, cable TV, or satellite systems—simple inline installation keeps your connections secure and your signals pristine. Digitek's isolator turns potential pitfalls into peace of mind—safeguard smarter, transmit smoother!

Key Features:

• 3kV Galvanic Isolation: Full DC isolation for 1 minute—like ultimate surge defense—protecting equipment from shocks, ground loops, or power faults.
• Excellent 5-1000MHz Screening: Capacitive/inductive coupling with 1.5dB/octave >40MHz—like noise-neutralizing precision—for clean HD signals without interference.
• Low Leakage Currents: 0.7mA inner/2.0mA RMS outer (230V 50/60Hz)—like minimal risk—complying with IEC 60728-1 §9 for safety in CATV installs.
• F-Type Female Output: Standard connector—like plug-and-protect simplicity—for inline boosts in antenna, cable, or satellite networks.
• EMC Compliant: Meets IEC 60728-2 §4.4—like certified clarity—for reliable, distortion-free transmission in professional or home environments.
• 1-Year Warranty: Digitek's assurance—like built-in confidence—for worry-free use in demanding RF applications up to 2000MHz.
