Hills Antenna BC15482B 2-Way Passive Splitter - Display Box

The Hills Antenna BC15482B 2-Way Passive Splitter is the perfect solution for dividing a single TV or satellite signal into two equal outputs, allowing multiple outlets in your home without compromising signal quality. Designed for TV and satellite applications across a wide frequency range of 5 – 2400MHz, this splitter ensures reliable performance for free-to-air and satellite systems.

Constructed with a durable zinc die-cast housing and tin-plated connectors, the BC15482B provides excellent shielding and low insertion loss, ensuring crisp, clear signal delivery to each connected outlet. Foxtel-approved (IPL #F30091) and featuring F-Type female connectors with all-port power pass, this splitter also includes an earthing lug for added safety if required.

Ideal for indoor installation, the splitter is best mounted close to the antenna, such as in a roof cavity, to maintain strong signal levels. It comes in a display box with mounting screws and earth screw included, offering a ready-to-install solution with 1-year warranty for peace of mind.

Features:

• Divides signal power into 2 equal outputs for dual TV outlets
• Foxtel Approved – IPL #F30091
• Suitable for Free-to-Air and Satellite signals
• Frequency range: 5 – 2400MHz
• F-Type female connections with all-port power pass
• Zinc die-cast housing with tin-plated connectors for durability
• Low insertion loss: 3.6dB – 5.5dB; return loss: 15dB – 17dB
• Excellent shielding: ≥100dB across 5 – 2400MHz
• Includes mounting screws and earth screw
• Packaged in a protective display box
• Designed for indoor installation, preferably near the antenna
• Backed by a 1-year warranty
