Hills Antenna BC84674 C-Block Bandpass Filter

The Hills Antenna Block C Filter is the professional installer’s choice when multiple TV transmitters are visible and you only want crystal-clear reception from the desired site on Channels 34 to 39 (568–610 MHz).

Used extensively across Australia in fringe areas, high-rise apartments and regional towns where strong off-air signals from distant towers cause pixelation or complete channel loss, this ultra-selective filter passes your wanted block with almost no loss while completely wiping out everything else – including 4G/5G LTE above 610 MHz.

Key Features & Benefits

• Genuine Australian-made Hills Antenna quality
• Passes only Block C: Channels 34–39 (568–610 MHz)
• Ultra-low insertion loss in-band: ≤4.0 dB
• Massive out-of-band rejection: – ≥30 dB from 5–544 MHz (blocks lower channels & FM) – ≥30 dB from 634–1000 MHz (eliminates LTE 700/5G interference)
• Return loss ≥10 dB
• Fully shielded die-cast housing
• F-type female connectors (in & out)
• Weatherproof – mast or wall mount
• No power required – 100 % passive
• 1-Year warranty

Get perfect reception on only the channels you want – order the genuine Hills Antenna Block C Filter today!
