Hills Antenna DY-6 VHF Antenna

SKU:: FB608007A
UPC:
MPN:

Description
Specifications
Details

Description

The Hills Antenna DY series antennas combine a F-Type connection for superior screening with wider bandwidth for digital television reception. The DY-6 antenna is a 6 element outer prime VHF antenna, ideal for areas just outside of capital cities.

Features:

F-type connectors for better shielding and more reliable connections
Heavy duty construction for extra strength
Rectangular galvanised steel boom construction provides element alignment
Powder coated boom for longer life and improved aesthetics
UV stable plastics for durability under harsh Australian conditions
Suitable for reception of horizontal or vertical polarisation

View AllClose

Specifications

4G Filter: False
Colour: Silver
Frequency: VHF
Frequency Range: 177-230MHz
Gain: 7-9dB
Material Type: Aluminum
Number of Channels: 6-12
Output Types: F-Type Female
Warranty: 1

View AllClose

Details

Antenna Category:	VHF
Antenna Band:	Band 3 (Channels 6 - 12)
Antenna Type:	Yagi
Antenna Elements:	6
Antenna Filter:	N/A
Antenna Max Gain:	6 - 8dB
Antenna Front to Back Ratio:	15 - 17dB
Antenna Materials:	Aluminium, UV Stabilised Plastics
Colour:	Silver
Antenna Dimensions:	1200mm x 835mm x 100mm (L x W x H)
Included Accessories:	Rubber Boot (For F Connector), V Block & U Bolt fitted to antenna
Unit Packaging:	Display Box
Warranty:	1 Year
Carton Quantity:	6
Pallet Quantity:	72
Product Information Sheet:	VIEW PDF
