Polytron SPM-UTCT Triple Tuner DVB-S/S2 / DVB-T/T2 / DVB-C to DVB-C/T Conversion Module

The Polytron SPM-UTCT is a high-performance professional signal conversion module designed for modern MATV and SMATV headend systems. Featuring an independent triple-tuner design, it allows complete freedom when selecting input sources—supporting DVB-S/S2 satellite, DVB-T/T2 terrestrial, and DVB-C cable signals.

The module converts two selected input signals into two high-quality DVB-C (QAM) or DVB-T (COFDM) output channels, making it ideal for hotels, commercial buildings, multi-dwelling units, and any large managed TV distribution infrastructure.

The SPM-UTCT includes a powerful channel regenerator delivering >38dB MER, ensuring exceptional signal stability and clarity. It also supports MPEG-2 and MPEG-4 content, LCN (Logical Channel Numbering), NIT modification, and transponder content editing (TSP removal), giving installers full flexibility over channel line-ups.

Setup is effortless with intuitive onboard LCD programming on the Polytron base unit—no PC required. Remote administration is also supported via the integrated LAN interface, enabling convenient off-site configuration.

Whether upgrading an existing system or deploying a new digital headend, the Polytron SPM-UTCT provides reliable performance, advanced tuning options, and professional-grade output quality.

Key Features:

• Converts two signals into two DVB-C (QAM) or DVB-T (COFDM) output channels
• Independent triple tuner supporting DVB-S/S2, DVB-T/T2, or DVB-C input
• Mix and match input sources (satellite, terrestrial, cable)
• High MER output (>38dB) for superior signal integrity
• Compatible with MPEG-2 and MPEG-4 broadcasts
• Adjustable output channels across 112–862MHz
• Transponder content editing (TSP removal)
• Supports LCN (Logical Channel Numbering)
• Supports Network Information Table (NIT) modification
• Easy configuration via LCD display on the base unit (no PC needed)
• LAN access for remote programming and management
• Professional-grade design for MATV/SMATV distribution systems
