Description
Dahua Pro Series NVR – 16 Channel 1.5U 16PoE 4HDD WizSense Network Video Recorder offers outstanding performance and high-grade technology that make it ideal for IP video surveillance applications. It has a powerful processor, that offers high access and forwarding bandwidth and strong decoding capabilities that together produce unimpeded streams. Thanks to its built-in AI chip and Dahua's advanced deep learning algorithms, the NVR supports a variety of AI functions, such as high-precision face recognition and perimeter protection. They shorten the response time to events and make videos more interactive. This NVR is compatible with numerous third-party devices, making it a great solution for surveillance systems that work with Video Management Software (VMS).
Features:
- Smart H.265+/H.265/Smart H.264+/H.264/MJPEG decoding format.
- 32-channel 1080p self-adaptive decoding capability.
- Max. 384 Mbps incoming/recording/outgoing bandwidth.
- AI by NVR: 2-channel face detection and recognition, 4-channel perimeter protection, 8-channel SMD Plus.
- AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, people counting.
- Security baseline 2.3.
Specifications
System Information
| Main Processor | Industrial-grade processor |
|---|---|
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
AI Information
| AI by Recorder | Face detection, face recognition, perimeter protection, and SMD Plus |
|---|---|
| AI by Camera | Face detection, face recognition, video metadata (human, motor vehicles, and non-motor vehicles), perimeter protection, SMD Plus, stereo analysis, crowd distribution, people counting, ANPR, vehicle density, heat map |
Perimeter Protection
| Perimeter Performance AI by Recorder (Number of Channels) | 4 channels, 10 IVS rules for each channel |
|---|---|
| Perimeter Performance of AI by Camera (Number of Channels) | 16 channels |
Face Detection
| Face Attributes | Gender, age group, glasses, expressions, face mask, beard |
|---|---|
| Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) | 16 channels |
Face Recognition
| Face Database Capacity | Up to 20 face databases with 200,00 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
|---|---|
| Face Recognition Performance of AI by Recorder (Number of Channels) | 1) 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s. 2) 2-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition Performance of AI by Camera (Number of Channels) | 16 channels |
SMD Plus
| SMD Plus by Recorder | 8 channels; Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain, and lighting condition change |
|---|---|
| SMD Plus by Camera | 16 channels |
Video Metadata
| Metadata Performance of AI by Camera (Number of Channels) | 8 channels |
|---|---|
| Human Attributes | Top color, top type, bottom color, bottom type, hat, bag, age, gender, and umbrella |
| Motor Vehicle Attributes | License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location |
| Non-motor Vehicle Attributes | Vehicle model, vehicle color, number of persons, helmet. |
Vehicle License Plate Comparison
| ANPR by Camera (Number of Channels) | 8 channels |
|---|---|
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers 2. Blocklist and allowlist |
Audio and Video Information
| Access Channel | 16 channels |
|---|---|
| Network Bandwidth | AI disabled: 384 Mbps incoming, 384 Mbps recording, and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording, and 200 Mbps outgoing |
| Resolution | 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF |
| Decoding Capability | See details in the provided information |
| Video Output | 2-channel VGA, 2-channel HDMI video output. Heterogeneous video source output for HDMI1 and HDMI2. Simultaneous video source output for VGA1 and HDMI1. Simultaneous video source output for VGA2 and HDMI2. Supports 4K display |
| Multi-screen Display | Main Screen: 1/4/8/9/16. Sub Screen: 1/4/8/9/16 |
| Third-party Camera Access | Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon |
Compression Standard
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
|---|---|
| Audio Compression | G.711a; G.711u; PCM; G726 |
Network Information
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register |
|---|---|
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome; IE9 and later; Firefox |
Recording Playback
| Multi-channel Playback | Up to 16 channels |
|---|---|
| Record Mode | General, motion detection; intelligent; alarm |
| Backup Method | USB device and network |
| Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
Alarm Information
| General Alarm | Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
|---|---|
| Anomaly Alarm | Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception |
| Intelligent Alarm | Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Alarm Linkage | Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
Port Information
| Audio Input | 1-channel RCA |
|---|---|
| Audio Output | 2-channel RCA |
| Alarm Input | 16 channels |
| Alarm Output | 6 channels (1-channel 12 V 1 A output) |
| HDD Interface | 4 SATA ports, up to 16 TB. The maximum HDD capacity varies with environment temperature. |
| eSATA | 1 |
| RS-232 | 1 |
| RS-485 | 1 (half-duplex serial communication) |
| USB | 3 (1 front USB 2.0 port, 2 rear USB 3.0 ports) |
| Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| PoE Port | 16 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE |
General Information
| Power Supply | 100–240 VAC, 50-60 Hz |
|---|---|
| Power Consumption | Total output of NVR is ≤ 13 W (without HDD) Total output power of PoE is 130 W, the maximum output power of a single port is 25.5 W |
| Net Weight | 4.82 kg (10.63 lb) |
| Gross Weight | 7.09kg (15.63lb) |
| Product Dimensions | 440.0 mm × 415.6 mm x 76.0 mm (17.32" × 16.36" × 3.00") (W ×D × H) |
| Package Dimensions | 530.0 mm × 500.0 mm × 210.0 mm (20.87" × 19.69" × 8.27") (W ×D × H) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH) |
| Installation | Rack or desktop |
| Certifications | FCC: 47 CFR FCC Part15, Subpart B, Class ACE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014CE-LVD: EN 62368-1:2014 |
