Digitek FM3 3-Element Yagi FM Antenna

SKU:
01EFM3
UPC:
9340591001750
Log in for pricing

Description

The Digitek FM3 FM Antenna is a robust 3-element Yagi design optimized for superior FM radio reception in Band 3 (88-108MHz), delivering 5dB forward gain and >15dB front-to-back ratio for clear, interference-free signals in urban or suburban setups. Crafted with heavy-duty 12mm extruded aluminum elements, stainless steel screws for corrosion resistance, and a tough powder-coated boom in charcoal hammertone finish with silver elements, this antenna withstands harsh Australian conditions thanks to UV-stabilized plastics. Featuring a high-performance F-Type balun for reliable connections, pre-fitted U-bolt and clamps, and included rubber boot for weatherproofing, it's easy to mount vertically or horizontally. Measuring 1020mm x 1540mm x 70mm (L x W x H), it's packaged in a poly bag with label and backed by a 3-year warranty—ideal for enhancing stereo systems or multi-room audio with strong, consistent FM performance.

Features:

  • 3-Element Yagi Configuration: Targeted FM Band 3 design provides 5dB forward gain and >15dB front-to-back ratio for focused, noise-reduced reception.
  • High-Performance F-Type Balun: Ensures seamless coaxial cable matching with minimal signal loss for optimal FM audio quality.
  • 12mm Extruded Aluminum Elements: Heavy-duty silver elements offer exceptional strength and durability against wind and weather.
  • Stainless Steel Screws: Corrosion-resistant fasteners at all connection points for long-lasting reliability in coastal or humid environments.
  • Tough Powder-Coated Boom: Charcoal hammertone finish protects the 1020mm boom from UV fading and environmental wear.
  • UV-Stabilized Plastics: Insulators and components resist cracking and degradation under intense Australian sun exposure.
  • Pre-Fitted Mounting Hardware: Includes U-bolt, clamps, V-block, and rubber boot for quick, secure rooftop or wall installation.
  • Compact Yet Robust Dimensions: 1020mm x 1540mm x 70mm (L x W x H) balances performance with easy handling and storage.
  • 3-Year Warranty: Manufacturer-backed assurance for peace of mind in residential FM stereo or broadcast applications.
View AllClose

Details

Antenna Category:
FM
Antenna Band:
Band 3 (FM)
Antenna Type:
Yagi
Antenna Elements:
3
Antenna Filter:
N/A
Antenna Max Gain:
FM 5dBi
Antenna Front to Back Ratio:
>15dB
Antenna Materials:
Aluminium, UV Stabilised Plastics
Colour:
Charcoal (Hammertone), Silver Elements
Antenna Dimensions:
1020mm x 1540mm x 70mm (L x W x H)
Included Accessories:
Rubber Boot (For F Connector), V Block & U Bolt fitted to antenna
Unit Packaging:
Poly Bag with Label
Warranty:
3 Years
Carton Quantity:
10
Pallet Quantity:
120
