Hills Antenna UHF/PL-259 Connector Male HEX Clamp for RG-213 Cable - Nickel Plated Body

SKU:
BC85281
UPC:
9340591015559
  • Hills Antenna BC85281 UHF Male PL-259 HEX Clamp Connector in nickel-plated brass, designed for RG-213 cable with 300MHz support
  • Close-up of Hills Antenna BC85281 PL-259 connector, showcasing HEX clamp design for secure RG-213 coax RF connections
Log in for pricing

Description

Ensure robust and reliable RF connectivity with the Hills Antenna BC85281 UHF Male PL-259 HEX Clamp Connector, a precision-engineered component designed specifically for RG-213 coax cables (BC85210/BC85211). Perfect for CB radio, amateur HAM radio, antenna installations, and marine VHF systems, this connector supports a frequency range from DC to 300 MHz with a 50 Ohm impedance, delivering low-loss signal transmission for optimal performance in Australian RF applications.

Crafted from nickel-plated brass, the BC85281 offers excellent conductivity and corrosion resistance, ensuring durability in harsh environmental conditions. Its HEX clamp design provides a secure, vibration-resistant connection, with centre and outer contact resistance ≤5mΩ, a withstanding voltage of 2000V r.m.s, and a working voltage of 750V r.m.s. The connector boasts insulation resistance ≥5000MΩ and a temperature range of -55°C to 155°C, making it suitable for extreme climates. With durability exceeding 500 cycles and RoHS compliance, this connector is built for long-term reliability in both domestic and commercial setups.

Key Features:

  • UHF Male PL-259 Connector: HEX clamp design for secure attachment to RG-213 coax cables.
  • High-Performance RF: Supports DC-300MHz with 50 Ohm impedance for clear signal transmission.
  • Durable Materials: Nickel-plated brass for superior conductivity and corrosion resistance.
  • Robust Specifications: 2000V withstanding voltage, 750V working voltage, ≥5000MΩ insulation, >500 cycles.
  • Versatile Applications: Ideal for CB radio, HAM, antennas, and marine VHF installations.

Backed by Hills Antenna’s Australian engineering expertise, the BC85281 UHF Male PL-259 Connector is the go-to choice for dependable RF connections. Order now for a high-quality, long-lasting solution to your coaxial needs.

View AllClose

Specifications

Impedance: 50Ω
Frequency Range: DC-300MHz
Centre Contact Resistance: ≤5mΩ
Outer Contact Resistance: ≤5mΩ
Withstanding Voltage: 2000V r.m.s
Working Voltage: 750V r.m.s
Insulation Resistance: ≥5000MΩ
Temperature Range: -55°C to 155°C
RoHS Complaint: YES
Durability: ≥500 cycles
View AllClose

Details

Connector Type:
UHF/PL-259 Male
Cable Type:
RG213 Coax Cable
Connection Type:
Clamp
Resistance:
50 Ohm
Materials:
Nickel Plated Body
Packaging:
Poly Bag with Label
Warranty:
1 Year
Carton Quantity:
-
