Description
The Hills Antenna FB601308B is a CA16 Regional Fringe VHF Antenna.
It's features are:
- VHF channels 6-12
- 16 elements
- Fringe signal antenna
Specifications
Antenna Type: Phased Array
4G Filter: False
Colour: Silver
Frequency: VHF
Frequency Range: 177-230MHz
Gain: 10-12
Material Type: Aluminium
Number of Channels: 6-12
Output Types: F-Type
Warranty: 1
View AllClose
4G Filter: False
Colour: Silver
Frequency: VHF
Frequency Range: 177-230MHz
Gain: 10-12
Material Type: Aluminium
Number of Channels: 6-12
Output Types: F-Type
Warranty: 1
Details
Antenna Category: |
VHF
|
Antenna Band: |
Band 3 (Channels 6 - 12)
|
Antenna Type: |
Phased Array
|
Antenna Elements: |
16
|
Antenna Filter: |
N/A
|
Antenna Max Gain: |
10 - 12dB
|
Antenna Front to Back Ratio: |
10 - 12dB
|
Antenna Materials: |
Aluminium, UV Stabilised Plastics
|
Colour: |
Silver
|
Included Accessories: |
Rubber Boot (For F Connector), V Block & U Bolt fitted to antenna
|
Unit Packaging: |
Single Piece with Label
|
Warranty: |
1 Year
|
