Description
Professional Series 8.0MP WDR Infrared Motorised Bullet
The VIP Vision Professional Series 8.0MP WDR Infrared Motorised Bullet Camera can remotely configure wide or narrow fields of view, allowing you to enjoy hassle free surveillance installation and adjustment should your surveillance requirements or environment change.
Features:
- Stream up to 8.0MP (3840 x 2160) at 25fps
- 3.7 ~ 11mm motorised varifocal lens with fixed iris
- 112°~46°(H) - 60°~26°(V) field of view with 5x optical zoom
- H.265 encoding for efficient storage & streaming
- Long 60m infrared range; true day/night (auto ICR)
- MicroSD slot for recording at the edge up to 128GB
- Back/highlight compensation & true WDR (120dB)
- 3D digital noise reduction & auto white balance
- IP67 weather rated housing for outdoor use
- ONVIF, PSIA and CGI compliance
Specifications
| Camera | |
|---|---|
| Image Sensor | 1/2" 8.0MP Progressive Scan CMOS |
| Max. Resolution | 8.0 Megapixel |
| Effective Pixels | 3840 (H) × 2160 (V) |
| RAM / ROM | 512MB / 128MB |
| Ultra Low Light Colour | Yes |
| Min. Illumination | 0.004 Lux/F1.9 (Color), 0 Lux/F1.9 (IR On) |
| S/N Ratio | >50dB |
| Infrared | Yes |
| Infrared System | 4 × Infrared LEDs, 60m Range, Auto/Manual On/Off Control |
| Lens | |
| Lens Type | Motorised Varifocal |
| Lens / Iris | 3.7 ~ 11mm F1.9 Motorised Varifocal Lens with Fixed Iris |
| Field of View | Horizontal: 112°~46°, Vertical: 60°~26° (5x Optical Zoom) |
| Focus | Auto Focus / 0.2m Minimum Focus Distance |
| DORI Detect | 83m (Wide) / 190m (Tele) |
| DORI Observe | 33m (Wide) / 76m (Tele) |
| DORI Recognise | 17m (Wide) / 38m (Tele) |
| DORI Identify | 8m (Wide) / 19m (Tele) |
| Video | |
| Resolution | 8.0MP (3840 × 2160) to CIF (352 × 288) |
| Frame Rate (Main) | 8.0MP (1 ~ 25fps) |
| Frame Rate (Sub) | D1 (1 ~ 25fps) |
| Frame Rate (Third) | N/A |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Bit Rate | H.265: 16 ~ 8192Kbps / H.264: 32 ~ 8192Kbps |
| Bit Rate Control | Constant Bit Rate (CBR) / Variable Bit Rate (VBR) |
| Day/Night | Auto (ICR) / Color / B&W |
| Lighting Compensation | BLC / HLC / WDR (120dB) |
| Smart Scene Adaptive (SSA) | Yes |
| White Balance | Auto / Natural / Street Lamp / Outdoor / Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | 3D DNR |
| Picture Control | Mirror / Flip (0°, 90°, 180°, 270°) (Resolution must be 4.0MP or lower for Corridor Mode) |
| IVS & Intelligent Functions | |
| IVS | Yes |
| Intelligent Functions | Motion Detection (4 Zones), Region of Interest (4 Zones), Privacy Masking (4 Zones), Smart Infrared, Tripwire, Intrusion |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | HTTP, HTTPS, TCP, ARP, RTSP, RTP, RTCP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPoE, IPv4/IPv6, QoS, UPnP, NTP, Bonjour, IEEE 802.1X, Multicast, ICMP, IGMP, TLS, NFS, SSH |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 20 Users |
| RTMP Support | No |
| Interface | |
| Video Interface | N/A |
| Audio Interface | N/A |
| Alarm Interface | N/A |
| RS485 | N/A |
| Edge Storage | MicroSD Card (up to 128GB) / NAS / Local PC |
| Interoperability | ONVIF / PSIA / CGI |
| Environmental | |
| Power Supply | 12VDC / PoE (802.3af) (Class 0) |
| Power Consumption | <14.3W |
| Operating Conditions | -30°C ~ +60°C / Less than 95% RH |
| Ingress Protection | IP67 |
| Weather Resistance | Yes |
| Vandal Resistance | N/A |
| Series | Professional Series |
| Camera Type | Bullet |
| Housing | Metal |
| Pan / Tilt / Rotation | Pan: 0° ~ 360° / Tilt: 0° ~ 90° / Rotation: 0° ~ 360° |
| Tri-Axis Mounting | No |
| ePoE | No |
| Physical | |
| Dimensions | 244 × 79 × 76mm |
| Net Weight | 0.82kg |
| Warranty (Years) | 4 |
| Shipping Weight and Dimensions | |
| Includes product packaging | |
| Width | 308 mm |
| Height | 145 mm |
| Depth | 156 mm |
| Weight | 1.13 kg |
Details
FBIRMD Pro Bullet Datasheet: |
|
Product Feature Guide - Corridor Mode: |
|
FBIRMD Pro Bullet Quick Installation Guide: |
|
Network Camera Web 3.0 Operation Manual V2.0.5: |
|
Accessory Compatibility Guide: |
