Hills Antenna FC658272A 694MHz 4G LP Outdoor Filter

The Hills Antenna FC658272A is the genuine Australian-made, professional-grade 694 MHz low-pass filter that completely eliminates 4G and 5G LTE mobile interference (703–803 MHz and above) that can wipe out digital TV channels 28–51.

With over 30 dB rejection of the entire LTE band and almost zero insertion loss on current Australian UHF TV channels (527–694 MHz), this is the filter trusted by installers nationwide when customers suffer pixelation, drop-outs or complete loss of signal caused by nearby mobile towers.

Install it at the masthead (between antenna and masthead amplifier/downlead—or directly at the wall plate for instant clean reception.

Key Features & Benefits

• Genuine Australian designed & manufactured by Hills Antenna
• Cuts off sharply at 694 MHz – fully compliant with ACMA Digital Dividend

• 30 dB rejection of 4G/5G LTE (703–803 MHz and higher)

• Ultra-low insertion loss: <2 dB on channels 28–51 (527–694 MHz)
• <0.5 dB on VHF Band 3 (174–230 MHz)
• Full zinc die-cast weatherproof housing – can be mast or wall mounted
• Integrated high-quality F-female connectors on both ends
• Built-in earth bonding point
• Return loss >15 dB – no signal reflection issues
• Passes DC power for masthead amplifiers
• 100 % weatherproof – perfect for coastal & rural installations
• 1-Year manufacturer warranty

Technical Specifications

• Passband: 47–694 MHz (VHF + UHF TV)
• Stopband: ≥30 dB rejection from 703 MHz upwards
• Insertion Loss: VHF <0.5 dB | UHF 527–694 MHz <2 dB
• Return Loss: VHF >20 dB | UHF >15 dB
• Connectors: F-type female (in & out)
• Housing: Zinc die-cast, fully shielded & weatherproof

What’s Included

• 1 × FC658272A 694 MHz low-pass filter
• Installation instructions

Installers who cannot utilise an internal filter due to access restrictions will benefit from adding this product at the antenna mast.

Fix 4G/5G interference permanently — add the industry-standard Hills Antenna FC658272A to your cart now and get perfect digital TV again!
